26-Pin 0.5 mm FFC Breakout Board

Prototype connection details

Adapt a 26-way flat-flex tail to accessible solder points or headers.

Flex / header pitch

0.5 mm

Positions

26

Connection

Fitted FFC connector; 2 × 13 through-holes at 2.54 mm

52 × 40 mm board with 3.5 mm mounting holes. Headers and cable selection are separate.

Selection and integration

Match pin count, pitch, contact side, flex thickness, connector footprint and signal assignment. A passive adapter does not convert voltage or protocol. Soldered headers or wires may be required; confirm the supplied assembly with your quotation.

Availability, configuration and project pricing are confirmed by quotation.
