30-Pin 0.5 mm FFC Breakout Board

Prototype connection details

Bring a 30-way display or peripheral flex out to prototype wiring.

Flex / header pitch

0.5 mm

Positions

30

Connection

Fitted FFC connector; 2 × 15 through-holes at 2.54 mm

Connector adaptation only. Match the exact electrical pin map before connecting a display or controller; a matching pin count does not establish LVDS or eDP compatibility.

Selection and integration

Match pin count, pitch, contact side, flex thickness, connector footprint and signal assignment. A passive adapter does not convert voltage or protocol. Soldered headers or wires may be required; confirm the supplied assembly with your quotation.

Availability, configuration and project pricing are confirmed by quotation.
