40-Pin 2 × 20 Header to Screw-Terminal Breakout

Prototype connection details

Bring a forty-pin header cable out to individual wires for bench testing.

Flex / header pitch

2.54 mm header

Positions

40

Connection

Male 2 × 20 header; individual screw terminals; benchtop feet

Screw terminals accept 16–26 AWG wire. Three solder pads per line support modifications. No direct FPC connector; use a separately matched FPC/header adapter and cable when needed.

Selection and integration

Match pin count, pitch, contact side, flex thickness, connector footprint and signal assignment. A passive adapter does not convert voltage or protocol. Soldered headers or wires may be required; confirm the supplied assembly with your quotation.

Availability, configuration and project pricing are confirmed by quotation.
