[LRA-03010-00] LRA / Cut-to-Fit LED Kit / 620 ×4 ×2 mm / Dual Strip
LRA / Cut-to-Fit LED Kit / 620 ×4 ×2 mm / Dual Strip

PN: LRA-03010-00

Kit sheet specifies two 620 ×4 ×2 mm strips with 99 LEDs per strip and a two-strip driver. Trim only at designated three-LED increments. Input is inconsistent within the sheet: 10–30 V in the specification and 9–30 V in the pin legend. Confirm the current driver rating and matched strip loading.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03009-00] LRA / Cut-to-Fit LED Kit / 540 ×4 ×2 mm / Dual Strip
LRA / Cut-to-Fit LED Kit / 540 ×4 ×2 mm / Dual Strip

PN: LRA-03009-00

Legacy sheet specifies two 540 ×4 ×2 mm strips with 96 LEDs per strip, driver and harness; designated three-LED cutting increments. Listed driver input 9–30 V DC. Confirm current SKU cross-reference and specifications before purchase.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03008-00] LRA / Cut-to-Fit LED Kit / 336 ×2 ×2 mm / Single Strip
LRA / Cut-to-Fit LED Kit / 336 ×2 ×2 mm / Single Strip

PN: LRA-03008-00

Kit includes one 336 ×2 ×2 mm strip, driver and harness. Listed 57 LEDs; trim only at designated three-LED increments. Driver input 9–30 V DC. Check electrical and optical fit; the diagonal range is a selection guide. No standalone PDF retrieved.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03007-00] LRA / Custom LCD LED Modification Kit / Family Reference
LRA / Custom LCD LED Modification Kit / Family Reference

PN: LRA-03007-00

Display-specific modification-kit family with a custom LED rail, LED driver, cables and installation materials as required. Exact kit PN and controlled drawings depend on the selected LCD. High-bright and dual-mode NVIS configurations require a display-specific design; no kit qualification is assigned here.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03006-00] LRA / White LED Rail / 321 ×5.1 ×2 mm / 6500 K
LRA / White LED Rail / 321 ×5.1 ×2 mm / 6500 K

PN: LRA-03006-00

Legacy standard rail: 321 ×5.1 ×2 mm; 6.9 mm LED spacing; 6500 K; listed input 1500 mA and 9.6 V. Confirm current availability and exact mechanical/driver configuration.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03005-00] LRA / White LED Rail / 258 ×5.1 ×2 mm / 6500 K
LRA / White LED Rail / 258 ×5.1 ×2 mm / 6500 K

PN: LRA-03005-00

Legacy standard rail: 258 ×5.1 ×2 mm; 6.9 mm LED spacing; 6500 K; listed input 1200 mA and 9.6 V. Confirm current availability and exact mechanical/driver configuration.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03004-00] LRA / White LED Rail / 220 ×5.1 ×2 mm / 6500 K
LRA / White LED Rail / 220 ×5.1 ×2 mm / 6500 K

PN: LRA-03004-00

Legacy standard rail: 220 ×5.1 ×2 mm; 6.5 mm LED spacing; 6500 K; listed input 1100 mA and 9.6 V. Drawing associates it with a matching light guide. Confirm current availability and drive limits.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03003-00] LRA / Custom Dual-Mode Day and NVIS Night LED Rail / Design Reference
LRA / Custom Dual-Mode Day and NVIS Night LED Rail / Design Reference

PN: LRA-03003-00

Custom rail with separately driven day and filtered night channels. Define optical isolation, drive leakage, source/filter geometry and thermal design. Check phosphor fluorescence from unpowered day LEDs. No completed or qualified assembly is represented.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03002-00] LRA / Custom Filtered NVIS Night LED Rail / Design Reference
LRA / Custom Filtered NVIS Night LED Rail / Design Reference

PN: LRA-03002-00

Custom night-channel rail design reference using source-matched infrared filters in chip, strip, cap or rail form. Specify NVIS class and output color separately. Define full light sealing, source spectrum, filter thermal clearance and assembly radiance test. No released or qualified design is represented.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[LRA-03001-00] LRA / Custom White Daylight LED Rail / Design Reference
LRA / Custom White Daylight LED Rail / Design Reference

PN: LRA-03001-00

Custom white-LED rail design reference. Define target LCD, length/width/height, emitting height, LED selection and pitch, current/string topology, connector/pinout, thermal interface, color bin and dimming. No completed rail, drawing or measured performance exists for this reference.

Development reference — further design or fit verification required. No target LCD has been selected. Confirm mechanical, electrical, optical and thermal compatibility before release.
Contact Us
[IRF-03025-00] IRF / Hot mirror, 45° incidence, 12.5 mm diameter / 12.5 mm diameter / 45° incidence
IRF / Hot mirror, 45° incidence, 12.5 mm diameter / 12.5 mm diameter / 45° incidence

PN: IRF-03025-00

Visible-transmitting, infrared-reflecting mirror for 45° incidence. Diameter 12.5 mm; thickness 1.10 ±0.20 mm. Average transmission exceeds 85% over 400–690 nm and average reflectance exceeds 95% over 750–1125 nm. No NVIS qualification is implied.

Development reference — further application development and verification required. Define the source, geometry, spectral limits and operating conditions before release. Finished-display NVIS compliance is not established.
Contact Us
[IRF-03024-00] IRF / Custom hybrid NVIS filter
IRF / Custom hybrid NVIS filter

PN: IRF-03024-00

Custom absorbing, reflective or combined filter for source-level, light-guide or display-window integration. Qualify the actual construction and source together.

Development reference — further application development and verification required. Define the source, geometry, spectral limits and operating conditions before release. Finished-display NVIS compliance is not established.
Contact Us
[IRF-03023-00] IRF / Custom laminated or monolithic NVIS filter
IRF / Custom laminated or monolithic NVIS filter

PN: IRF-03023-00

Custom source or display filter using glass, polymer, coating or laminated construction. Define the required NVIS class, output color, environment and complete spectral limits.

Development reference — further application development and verification required. Define the source, geometry, spectral limits and operating conditions before release. Finished-display NVIS compliance is not established.
Contact Us
[IRF-03022-00] IRF / Custom NVIS interference filter, design family 02
IRF / Custom NVIS interference filter, design family 02

PN: IRF-03022-00

Custom infrared-blocking coating on glass for NVIS or dual-mode backlights. Specify the LED spectrum, cutoff, transition slope, blocking band, angle range and chip, strip or window dimensions.

Development reference — further application development and verification required. Define the source, geometry, spectral limits and operating conditions before release. Finished-display NVIS compliance is not established.
Contact Us
[GLS-500007-00] IRF / Green-output absorbing filter glass, 2.00 mm
IRF / Green-output absorbing filter glass, 2.00 mm

PN: GLS-500007-00

Absorbing glass for NVIS Green A output development. Nominal thickness 2.00 mm. Published luminance transmission ranges from 17.8% to 18.7% across three specified white LEDs.

Development reference — further application development and verification required. Define the source, geometry, spectral limits and operating conditions before release. Finished-display NVIS compliance is not established.
